A 72-core optical fiber cable typically uses multiple color-coded buffer tubes, each containing 12 fibers in the standard 12-color sequence, with the outer jacket color indicating the fiber type.

Outer Jacket Color

The outer jacket of the cable indicates the fiber type:

• Yellow for single-mode fibers (OS1/OS2)
• Aqua for OM3/OM4 multimode fibers
• Erika Violet may be used for OM4 in some high-density data centers
• Lime Green for OM5 multimode fibers supporting SWDM applications .

Buffer Tube and Fiber Colors

A 72-core cable is typically divided into 6 buffer tubes, each containing 12 fibers. Each tube follows the TIA-598-C 12-color sequence for individual fibers:

1. Blue
2. Orange
3. Green
4. Brown
5. Slate (Gray)
6. White
7. Red
8. Black
9. Yellow
10. Violet
11. Rose (Pink)
12. Aqua The buffer tubes themselves are also color-coded to distinguish each 12-fiber group. For example, the first tube might be Blue, the second Orange, the third Green, and so on .

Identifying Individual Fibers

To identify a specific fiber in a 72-core cable:

1. Determine the tube number (based on the fiber's position in the 12-fiber groups).
2. Identify the fiber color within that tube using the 12-color sequence. For instance, fiber #34 would be in the 3rd buffer tube (Green tube) and be the 10th fiber within that tube (Violet fiber), .

Summary

• Outer jacket color: indicates fiber type (Yellow, Aqua, Erika Violet, or Lime Green)
• Buffer tube colors: distinguish each 12-fiber group
• Individual fiber colors: follow the 12-color TIA-598-C sequence within each tube This hierarchical color system ensures easy identification, safe installation, and error-free splicing in high-density fiber optic networks .
