Relay protection settings are calculated using system parameters to determine pickup currents, time delays, and coordination for overcurrent, differential, and line protection relays.

Key Relay Setting Calculations

1. Pickup Current (Ip)
   • Defines the minimum fault current at which the relay operates.
   • Calculated using load current, CT ratio, and plug setting multiplier (PSM): $$I_p=I_{load}\times PSM$$
   • Example: For a load current of 150 A and PSM of 125%, the pickup current is 187.5 A, rounded to the nearest standard setting, e.g., 200 A .
2. Time Multiplier Setting (TMS)
   • Determines the operating time of the relay based on the fault current.
   • Used with standard inverse, very inverse, extremely inverse, or long-time inverse curves.
   • Operating time formula: $$t=TMS\times f(I_{fault}/I_p)$$
   • Ensures proper coordination with downstream relays .
3. Plug Setting Multiplier (PSM)
   • Ratio of fault current to relay pickup current: $$PSM=\frac{I_{fault}}{I_p}$$
   • Helps in adjusting relay sensitivity for different fault levels .
4. Coordination Time Interval (CTI)
   • Time difference between upstream and downstream relay operation to ensure selectivity.
   • Typically 0.2–0.5 seconds for distribution systems.
   • Calculated using relay operating times and system fault levels .
5. Transformer Differential Relay Settings (e.g., SEL-787)
   • Uses per-unit TAP scaling to normalize secondary currents from multiple windings.
   • TAPn is set for each winding to ensure full-load through-current sums to 1.0 per unit.
   • Maximum ratio constraint: $TA{P}_{max}/TA{P}_{min}\le 7.5$, .
6. Line Protection IED Settings
   • Includes overcurrent, distance, and directional elements.
   • Calculations based on system parameters: line impedance, fault current, CT ratios, and relay curve type.
   • Default settings may be adjusted according to manufacturer manuals and CBIP guidelines .
7. Other Protection Elements
   • Busbar, reactor, and generator protection relays may require:
     • Overcurrent and earth fault pickup currents
     • Time delays for backup protection
     • Supervision functions (e.g., breaker failure, voltage supervision)
   • Calculations follow similar principles: determine fault current, select pickup, apply TMS, and ensure coordination .

Practical Notes

• Always verify relay settings during commissioning with actual measured values.
• Consider selectivity and coordination to prevent unnecessary tripping.
• Document all settings, including unused functions, for future reference and troubleshooting.
• Use interactive calculators or software tools to simplify calculations and reduce errors . This structured approach ensures reliable protection, selectivity, and minimal disruption in power systems.
